The Caryaire CDIF Direct Drive Cabinet Fan is a compact, Built with galvanized steel housing and optional insulated design, it ensures efficient air circulation for HVAC, commercial, and industrial spaces.
Caryaire Direct Drive Cabinet Fan – CDIF Series sales and service
Caryaire Direct Drive Cabinet Fan – CDIF-09 (CDIF Series)
Technical Specifications (Based on CDIF-09 Standard Version)
From the official CDIF product documentation:
- Construction: Built with galvanized steel cabinet, available in single-skin (standard) or insulated (double-skin) with 25 mm glass wool and perforated inner sheet
- Motor: Single-phase squirrel cage induction motor with sealed-for-life bearings, multi-speed (selector switch included), Insulation Class B, and IP20 protection
- Impeller: High-efficiency forward-curved impeller (DIDW style) with galvanized steel scroll
- Mounting & Convenience: Features mounting brackets and access panels as standard. Filter fixing arrangement is standard (pre-filters optional)
- Optional EC Motor Variant: EC (Electronically Commutated) motor versions are available upon request (CDIF-EC series)
Specific data for the CDIF-09 model (standard vs. insulated):
|
Specification
|
Standard (CDIF-09)
|
Insulated (CDIF-09-IS)
|
|
Poles
|
4
|
4
|
|
Power
|
370 W
|
—
|
|
Frequency
|
50 Hz
|
—
|
|
Insulation Class
|
B
|
—
|
|
Voltage
|
220–240 V
|
—
|
|
Rated Current
|
3.2 A
|
—
|
|
Max Current
|
4.7 A
|
—
|
|
Noise Levels**
|
56 / 52 / 48 / 41 dB(A) @ 3 m (H / MH / ML / L)
|
52 / 48 / 44 / 37 dB(A) @ 3 m
|
|
Weight
|
~29 kg
|
~30 kg
|
*Noise levels correspond to different speed settings: High (H), Medium-High (MH), Medium-Low (ML), and Low (L).
Key Features
- Galvanized steel cabinet, durable and corrosion-resistant.
- Efficient airflow via backward-curved impeller.
- Multi-speed control directly on the unit (no external controller needed).
- Low-noise operation, especially in insulated versions.
- Ease of maintenance with access panels and optional filters.
- Optional EC motor for enhanced energy efficiency and control flexibility.
- Versatile mounting, suitable for ceiling or floor installation.
Typical Applications
- General ventilation and exhaust in industrial or commercial environments.
- Suitable for equipment cabinet cooling, control room ventilation, and air circulation in enclosed spaces.
- Ideal where adjustable airflow, low noise, and rugged construction are essential.
- The insulated variant (CDIF-09-IS) fits well in acoustically sensitive areas like office spaces or laboratories.
